Compatibility: Supports Intel LGA1851/1700 and AMD AM5/AM4 sockets.
High-Performance Cooling: 280mm radiator with 38mm thickness and 23% larger cooling surface for efficient heat dissipation.
PWM-Controlled Pump: Optimized for performance and low noise.
VRM Fan: 60mm PWM fan for silent cooling of motherboard voltage converters.
ARGB Lighting: Customizable RGB on pump head and P14 PWM PST ARGB fans.
Integrated Cable Management: Fan cables hidden in hose sleeving for a clean look.
AMD Offset Mounting: 5mm offset for optimal Ryzen chiplet cooling.
Contact Frame: Reduces CPU deformation for Intel CPUs, improving heat transfer.
Pre-Installed Fans: Two 140mm P14 PWM PST ARGB fans (200–1700 RPM).
M.2 Cooler Compatibility: Free M.2 cooler provided for affected motherboards.
Warranty: 6-year warranty with included MX-6 thermal paste.
|
Brand |
ARCTIC |
|
Model |
ACFRE00183A |
|
Color |
Black |
|
General Specifications |
|
|
TIM |
MX-6 (0.8 g) |
|
Operating Ambient Temperature |
0°C - 40°C |
|
Pump |
800 - 2800 RPM (PWM controlled) |
|
Current / Voltage |
0.35 A / 12V DC |
|
Cold Plate |
Copper, Micro Slotted Fins |
|
Tube Length |
450 mm |
|
Tube Diameter |
Outer: 12.4 mm, Inner: 6.0 mm |
|
Weight |
1977 g |
|
Compatibility |
|
|
Intel |
LGA1851, LGA1700 |
|
AMD |
AM5, AM4 |
|
Radiator |
Aluminium |
|
Dimensions |
|
|
Radiator Module |
317(L) x 138(W) x 33(H) mm |
|
VRM Bracket |
|
|
Voltage |
0.05 A / 12V DC (PWM controlled) |
|
Current / Voltage |
0.05 A / 12V DC |
|
LEDs |
12x A-RGB GEN2 LEDs |
|
Current / Voltage |
0.40 A / 5V DC |
|
Radiator Fan |
|
|
General |
2x P14 Pro A-RGB |
|
Speed |
400 - 2000 RPM |
|
Airflow |
112 cm³/h (186 m³/h) |
|
Static Pressure |
5.2 mmH2O |
|
Bearing |
Fluid Dynamic Bearing |
|
Current / Voltage |
0.35 A / 12V DC |
|
Connector |
4-Pin Fan Plug |
|
RGB |
|
|
LEDs |
12x A-RGB GEN2 LEDs |
|
Current / Voltage |
0.40 A / 5V DC |
|
Connector |
3-Pin A-RGB Plug + 3-Pin Socket |
|
Packaging |
|
|
Height |
170 mm |
|
Width |
135 mm |
|
Length |
335 mm |
|
Weight |
2.914 kg |
|
Warranty |
6 Years |
|
Note |
**Features, Price, Specifications are subject to change without notice. Images used for representation purpose only. |
